IPS X303 Series Instruction Manual
36
SAVE/RECALL SETUP
Save Setup
Background
The front panel settings can be stored into one of the four internal
memories.
Contents
The following list shows the setup contents.
 Independent / tracking series / tracking parallel mode
 CH1/CH2 knob selection
 Fine/coarse editing mode
 Output voltage/current level
The following settings are always saved as “off”.
 Output on/off
 Front panel lock/unlock
 Buzzer on/off
Panel operation
Press one of the 1 to 4 Memory keys for 2
seconds, for example memory 1. The panel
settings are saved in memory 1 and the key LED
turns on. When the panel settings are modified,
the LED turns off.
RECALL /
MEMORY
SAVE
1
2
3
4
RECALL /
MEMORY
SAVE
1
2
3
4
Note
When a setting is stored, the output automatically turns off.
