OVERVIEW
9
OVERVIEW
This chapter describes the IPS X303 series in a nutshell, including its
main features and front / rear panel introduction. After going through the
overview, follow the Setup chapter (page 20) to properly power up and
set operation environment.
Introduction
The IPS X303 regulated DC power supply series, are light weight,
adjustable, multifunctional work stations. The IPS 2303S has two
adjustable voltage outputs. The IPS 3303S has three independent
outputs: two with adjustable voltage level and one with fixed level
selectable from 2.5V, 3.3V and 5V. The IPS 4303S has four independent
voltage outputs that are all fully adjustable. The IPS X303 series can be
used for logic circuits where various output voltage or current are
needed, and for tracking mode definition systems where plus and minus
voltages with insignificant error are required.
Independent /
Tracking Series /
Tracking Parallel
The three output modes of IPS X303 series, independent, tracking
series, and tracking parallel, can be selected through pressing the
TRACKING key on the front panel. In the independent mode, the output
voltage and current of each channel are controlled separately. The
isolation degree, from output terminal to chassis or from output terminal
to output terminal, is 300V. In the tracking modes, both the CH1 and CH2
outputs are automatically connected in series or parallel; no need to
connect output leads. In the series mode, the output voltage is doubled;
in the parallel mode, the output current is doubled.
