REMOTE CONTROL
45
STATUS?
Description
Returns the IPS 3303D or IPS X303S status.
Response time
Minimum 10ms
Contents
8 bits in the following format
Bit
Item
Description
0
CH1
0=CC mode, 1=CV mode
1
CH2
0=CC mode, 1=CV mode
2, 3
Tracking
01=Independent, 11=Tracking series, 10=Tracking
parallel
4
Beep
0=Off, 1=On
5
N/A
N/A
6
Output
0=Off, 1=On
7
N/A
0=115200bps，1=57600bps
*IDN?
Description
Returns the IPS 3303D or IPS X303S identification.
Response time
Minimum 10ms
Contents
Iso-tech, IPS X303x,SN: xxxxxxxx, Vx.xx
(Manufacturer, model name, serial number, firmware version)
RCL<NR1>
Description
Recalls a panel setting.
<NR1>
1 – 4: Memory 1 to 4
Response time
Minimum 10ms
Example
RCL1
Recalls the panel setting stored in memory 1
SAV<NR1>
Description
Stores the panel setting.
<NR1>
1 – 4: Memory 1 to 4
Response time
Minimum 10ms
Example
SAV1
Stores the panel setting in memory 1
