IPS X303 Series Instruction Manual
50
Meter Resolution
IPS 3303D
Voltage: 100mV
Current: 10mA
IPS X303S
Voltage: 1mV
Current: 1mA
A Meter
IPS 3303D
3.2A full scale, 3 digits 0.5" LED display
IPS X303S
3.2A full scale, 4 digits 0.4" LED display
V Meter
IPS 3303D
32V full scale, 3 digits 0.5" LED display
IPS X303S
32V full scale, 5 digits 0.4" LED display
Program Accuracy
IPS 3303D
Voltage: ± (0.5% of reading + 2digits)
Current: ± (0.5% of reading + 2digits)
IPS X303S
Voltage: ± (0.03% of reading + 10mV)
Current: ± (0.3% of reading + 10mA)
Readback Accuracy
IPS 3303D
Voltage: ± (0.5% of reading + 2digits)
Current: ± (0.5% of reading + 2digits)
IPS X303S
Voltage: ± (0.03% of reading + 10mV)
Current: ± (0.3% of reading + 10mA)
Overvoltage
Protection
CH1/CH2
≥35V
CH3
≥11V
CH4
≥6V
Insulation
Chassis and
Terminal
20MΩ or above (DC 500V)
Chassis and AC
cord
30MΩ or above (DC 500V)
Operation
Environment
Indoor use, Altitude: ≤ 2,000m
Ambient temperature 0 to 40°C
Relative humidity ≤ 80%
Installation category: II, Pollution degree: 2
Storage
Environment
Ambient temperature –10 to 70°C
Relative humidity ≤ 70%
Power Source
AC 100V/120V/220V/230V±10%, 50/60Hz
Accessories
User manual x1
Test lead GTL-104A x 2, GTL-105A x 1
(Europe) Test lead GTL-203A x 1, GTL-204A x 2
Dimensions
210 (W) x 130 (H) x 265 (D) mm
Weight
Approx. 7kg
