#14
www.istorage-uk.com
18. How to determine the device Version Number in Admin mode
Instructions LED LED State
1. Unlock the datAshur Personal
2
with Admin PIN
Red solid LED followed by a flickering Green
LED indicating successful Admin PIN entry
2. Press the KEY button three times
(triple-click)
&
Green and Blue LED’s flicker together
3. Within 10 seconds begin to press the number 8 (tuV)
button followed by the number 6 (mNo) button (86)
&
Green and Blue LED’s continue to flicker
together
4. Press KEY button once
Red, Green & Blue LED’s will quickly blink
together once followed by the Red LED blinking
to the most significant digit of revision and
the Green LED will blink according to the least
significant digit of the revision number
For example, if the revision number is ‘1.9’, the Red LED will blink once (1) and the Green LED will blink nine (9) times.
Once the sequence has ended the Red, Green & Blue LED’s will blink together once and then to flickering Green LED.
Instructions LED LED State
1. Unlock the datAshur Personal
2
with Admin PIN
Red solid LED followed by a flickering Green
LED indicating successful Admin PIN entry
2. Press the KEY button three times
(triple-click)
&
Green and Blue LED’s flicker together
3. Within 10 seconds begin to press the number 7 (pqRs)
button followed by the number 9 (Wxyz) button (79)
&
Green and Blue LED’s continue to flicker
together
4. Press KEY button once
Blue LED quickly fades out and Green LED con-
tinues to flicker. when the datAshur Personal
2
is
inserted into a USB port the Green LED is solid
indicating the datAshur Personal
2
is Read/Write
enabled
To display the device Version Number of the datAshur Personal
2
do the following.
Caution: Entering the Admin PIN to access a locked drive will clear the User PIN. For security reasons, we
highly recommend that a new User PIN be created immediately once the drive has been unlocked
using the Admin PIN. Refer to section 13 on page 11.
