Inspection and Installation
3. Use left and right keys or rotate the knob to select LAN and press [Enter]
key to confirm.
The first displayed menu item Lan Info is to view the LAN interface
information.
4. Press [Enter] key to confirm.
5. Use left and right keys or rotate the knob to view the LAN interface informa-
tion. Refer to System Menu for more information.
6. After setting, press [Esc] to exit.
Enable LAN Service
The configurable services include: mDNS, Ping, Web, VXI-11 and Raw Socket.
When using the LAN interface, these services are enabled by default and can
be used directly. When using the Raw Socket function, you need to set the
Socket Port number, please refer to the following steps:
1. Press [Shift]+[Save] (System) to enter into the system menu interface.
2. Use left and right keys or rotate the knob to select Comm and press [Enter]
key to confirm.
3. Use left and right keys or rotate the knob to select LAN and press [Enter]
key to confirm.
4. Use left and right keys or rotate the knob to select Lan Config and press
[Enter] key to confirm.
5. Use left and right keys or rotate the knob to select Server Config and press
[Enter] key to confirm.
6. Select the Socket Port and press [Enter] key to confirm.
7. Rotate the knob to adjust the parameter and press [Enter] key to confirm.
8. After setting, press [Esc] to exit.
2.6.2.1 Web Interface
The instrument has a built-in Web interface for monitoring and controlling the in-
strument via a Web browser. To use the Web interface, connect the instrument
and PC over LAN and enter the instrument's IP address into the address bar at
the top of your PC's Web browser, you can access the front panel control func-
tions including the LAN configuration parameters.
The instrument supports simultaneous connection to up to 6 computers. If
there are more connections, the instrument performance will be reduced.
Press the Enter key, the Web interface will appear in the browser as shown be-
low. The following figure is just as an example and the Web interface of different
models are different. The actual shown page shall be subject to the connected
instrument.
Copyright © Itech Electronic Co., Ltd.
29
