ITech IT8200 Series User Manual

Technical Specifications
Copyright ©ITECH Electronic Co., Ltd. 101
Apparent power
Range
0 ～ 5
KVA
Resolution
0.001
KVA
Accuracy
＜ 0.4% +0.4%
F.S.
CF
Range
1 ～ 5
Resolution
0.01
PF
Range
0.1 ～ 1
Resolution
0.01
Accuracy
1%F.S
.
Harmonic
measurement
Max.
50/60Hz
up to 50
orders
Regenerative power
Max.
Regenerative
power
5k
VA
ITHD
< 5%
Other
Efficiency
typ
88%
Protection
OVP ， OCP ， OPP ， OTP ， FAN ， Sense ， UVP ， FE
dimension
483.00mm （ W ） *151.30mm （ H ） *700.00mm （ D ）（ 841.60mm include cover and
handle)
Weight
26.4kg
Working
temperature
0 ℃ -50 ℃
Programming
response time
2ms
Communication
interface
Built-in USB/CAN/LAN/Digital IO interface, optional GPIB / Analog&RS232
*1 supports single phase 220V input, power cord connecting refer to manual.
*2 Max. Output derated to 3kW when input with (200-220)±10% Vac
*3 Under the output frequency of 50Hz/60Hz, the maximum CF is 5 without exceeding the peak current; under the condition of full current
and full power, the maximum CF is 3.
*4 When frequency <150Hz, the minimum current for test need to be 1%F.S. frequency >150Hz, the minimum current for test need to be 3%F.S.
*5 When loopSpeed Low is low ， it can better complied DUT’s characteristics ； When LoopSpeed is High ， the dynamic response time is faster.
*6 Frequency <150Hz, the specification is meet.
*7 In the rectifier load mode, the setting range of phase Angle is related to CF. The larger CF is, the larger the range of phase Angle can be set.
IT8206-350-90
Grid parameters
AC input
Wiring connection
3 phase 3wire + ground(PE)
Line voltage
RMS
( 200 ～ 220 ) ±10% *1
( 380 ～ 480 ) ±10%
V
Line current
RMS
< 14
A
Apparent power
< 7
kVA
Frequency
45 ～ 65
Hz
Power factor
typ
0.98
Input parameters
Input voltage
VLN
30 ～ 350
V
VLL （ 3phase ）
51.96 ～ 606
V LL （ reverse ）
60 ～ 700
V
Input Frequency
DC ， 16~500
Hz
Input current
RMS （ 1phase ）
90
A
Crest Factor *2
5
Peak （ 1phase ）
270
A
RMS
(3phase/reverse)
30
A
Peak
(3phase/reverse )
90
A
Input power
Per Phase
(3phase )
2k
VA
Max. Power
（ reverse phase )
4k
VA
Max. Power
（ 1phase/3phase ）
6k
VA
CC Mode
Current Range
RMS
（ 1phase ）
90
A
RMS
(3phase/reverse)
30
A
Resolution
0.01
A
Accuracy*3
DC,16Hz ～ 150Hz
＜ 0.1% + 0.2%
F.S.
A
150.01Hz ～ 500Hz
＜ 0.2% + 0.3%
A
