ITech IT8200 Series - It8245-350-270

Technical Specifications
Copyright ©ITECH Electronic Co., Ltd. 113
Programming
response
time
2ms
Communication
interface
Built-in USB/CAN/LAN/Digital IO interface, optional GPIB / Analog&RS232
*1 ( 200 ～ 220 ) ±10%, 3 phase AC input, 60% of the rated power output for 12Kw and above models.
*2 Under the output frequency of 50Hz/60Hz, the maximum CF is 5 without exceeding the peak current; under the condition of full current and full
power, the maximum CF is 3.
*3 When frequency <150Hz, the minimum current for test need to be 1%F.S. frequency >150Hz, the minimum current for test need to be 3%F.S.
*4When loopSpeed Low is low ， it can better complied DUT's characteristics ； When LoopSpeed is High ， the dynamic response time is
*5 Frequency <150Hz, the specification is meet.
*6 In the rectifier load mode, the setting range of phase Angle is related to CF. The larger CF is, the larger the range of phase Angle can be set.
IT8245-350-270
Grid parameters
AC input
Wiring
connection
3 phase 3wire +
ground(PE)
Line voltage
RMS
( 200 ～ 220 ) ±10% *1
( 380 ～ 480 ) ±10%
V
Line current
RMS
< 100
A
Apparent power
< 52
kVA
Frequency
45 ～ 65
Hz
Power factor
typ
0.98
Input parameters
Input voltage
VLN
30 ～ 350
V
VLL （ 3phase ）
51.96 ～ 606
V LL （ reverse ）
60 ～ 700
V
Input Frequency
DC ， 16~500
Hz
Input current
RMS （ 1phase ）
270
A
Crest Factor *2
5
Peak （ 1phase ）
810
A
RMS
(3phase/reverse)
90
A
Peak
(3phase/reverse )
270
A
Input power
Per Phase
(3phase )
15k
VA
Max. Power
（ reverse phase )
30k
VA
Max. Power
（ 1phase/3phase ）
45k
VA
CC Mode
Current Range
RMS
（ 1phase ）
270
A
RMS
(3phase/reverse)
90
A
Resolution
0.01
A
Accuracy*3
DC,16Hz ～ 150Hz
＜ 0.1% + 0.2%
F.S.
A
150.01Hz ～ 500Hz
*4
＜ 0.2% + 0.3%
F.S.
A
Temperature coefficient
< 200ppm/ ℃ F.S
CP Mode
Range
Max. Power
（ 1phase/3phase ）
45k
W
Max. Power
（ reverse phase )
30k
W
Per Phase
(3phase )
15k
W
Resolution
0.001
kW
Accuracy
DC,16Hz ～ 500Hz
＜ 0.4% +0.4%
F.S.
Temperature
< 200ppm/ ℃ F.S.
AC Mode
CS Mode
Range
Max. Power
（ 1phase/3phase ）
45k
VA
Max. Power
（ reverse phase )
30k
VA
Per Phase
(3phase )
15k
VA
Resolution
0.001
kVA
Accuracy
DC,16Hz ～ 500Hz
＜ 0.4% +0.4%
F.S.
Temperature
< 200ppm/ ℃ F.S.
CR Mode
Range
1phase
0.12 ～ 130
Ω
Per Phase
(3phase )
0.34 ～ 389
Ω
reverse phase
0.67 ～ 778
Ω
Resolution
0.001
Ω
Accuracy*5
.
0.4%+0.4%F.S.
Ω
