Menu Introduction
Press the [Menu] key on the front panel and enter to the menu interface. Menu
interface will display all of function icon, user can rotate the knob or direction key
to select, or click the screen to enter the function interface.
4.3 Set load parameters
IT8200 AC/DC electronic load supports the function of AC load, DC load and
several function mode. The current value and power value can be programmed,
which can be set to different parameters within the specification range based on
customer requirements. This can meet various test requirements of the
customer.
After the user presses the Set or Set keys on the front panel, the instrument
interface displays the parameters to be set and the cursor flashes for prompt.
The user can use the following methods to set the values.
⚫ Directly use the number keys to set the value.
⚫ Rotate the knob to set the data in the cursor position. Rotate the knob
clockwise to increase the set value and anticlockwise to decrease the set
value. Once the data in the cursor position increases to ten, the value will
add one to the front position automatically. and once the data in the cursor
position decreases to zero, the value will minus one from the front position
automatically. This provides convenience for the user to set. The knob can
works with the left or right keys. Use the left or right keys to move the cursor
position.
