ITech IT8200 Series User Manual

Technical Specifications
Copyright ©ITECH Electronic Co., Ltd. 103
work mode
CC, CV, CR, CP ， CC+CV ， CR+CV ， CP+CV ， CC+CR ， CC+CV+CP+CR
Measurement parameter
Voltage RMS
Range
0 ～ 350
Vrms
Resolution
0.01
Accuracy
DC,16Hz ～ 500Hz
＜ 0.1%+0.1%
F.S.
Temperature
< 100ppm/ ℃ F.S.
Current RMS
Range
0 ～ 90
A
Resolution
0.01
A
Accuracy
DC,16Hz ～ 150Hz
＜ 0.1% + 0.2%
F.S.
150.01Hz ～ 500Hz
＜ 0.2% + 0.3%
F.S.
Temperature
< 200ppm/ ℃ F.S.
Peak current
Range
0 ～ 270
A
Resolution
0.1
Accuracy
＜ 0.3% + 0.6%
F.S.
Active power
Range
0 ～ 6
kW
Resolution
0.001
kW
Accuracy
＜ 0.4% +0.4%
F.S.
Reactive power
Range
0 ～ 6
kVAR
Resolution
0.001
kVAR
Accuracy
＜ 0.4% +0.4%
F.S.
Apparent power
Range
0 ～ 6
KVA
Resolution
0.001
KVA
Accuracy
＜ 0.4% +0.4%
F.S.
CF
Range
1 ～ 5
Resolution
0.01
PF
Range
0.1 ～ 1
Resolution
0.01
Accuracy
1%F.S.
Harmonic
measuremen
t
Max.
50/60Hz
up to 50
orders
Regenerative power
Max.
Regenerativ
e power
6k
VA
ITHD
< 5%
Other
Efficiency
typ
88%
Protection
OVP ， POVP ， OCP ， POCP ， +OPP ， -OPP ， OTP ， FAN ， ECP ， Sense ， UVP ， FE
dimension
483.00mm （ W ） *151.3mm （ H ） *700mm （ D ）（ 841.6mm include cover and handle)
Weight
42kg
Working
temperature
0 ℃ -50 ℃
Programming
response
time
2ms
Communication
interface
Built-in USB/CAN/LAN/Digital IO interface, optional GPIB / Analog&RS232
*1 ( 200 ～ 220 ) ±10%, 3 phase AC input, 60% of the rated power output for 12Kw and above models.
*2 Under the output frequency of 50Hz/60Hz, the maximum CF is 5 without exceeding the peak current; under the condition of full current and full
power, the maximum CF is 3.
*3 When frequency <150Hz, the minimum current for test need to be 1%F.S. frequency >150Hz, the minimum current for test need to be 3%F.S.
*4When loopSpeed Low is low ， it can better complied DUT’s characteristics ； When LoopSpeed is High ， the dynamic response time is
*5 Frequency <150Hz, the specification is meet.
*6 In the rectifier load mode, the setting range of phase Angle is related to CF. The larger CF is, the larger the range of phase Angle can be set.
IT8209-350-90
Grid parameters
AC input
Wiring
connection
3 phase 3wire +
ground(PE)
Line voltage
RMS
( 200 ～ 220 ) ±10% *1
( 380 ～ 480 ) ±10%
V
Line current
RMS
< 20
A
Apparent power
< 10
kVA
Frequency
45 ～ 65
Hz
Power factor
typ
0.98
