Overview
Copyright ©ITECH Electronic Co., Ltd. 10
⚫ Built-in USB/CAN/LAN/Digital IO interface, optional GPIB/Analog&RS232
⚫ DC mode supports nine working modes, including CC, CR,CP, and CV
⚫ AC mode supports CC/CP/CR/CS/CC+CR/CE multipleworking modes, CE
mode can simulate various circuit topologies such as single-phase rectifier
RLC and parallel RLC
⚫ AC mode supports both rectification and non-rectification modes
⚫ Adjustable crest factor: 1.414 ~ 5.0
⚫ Supports phase shift, ranging from -90 º to 90.0 º *1
⚫ The unit power factor1 function allows the current waveform to vary with
the voltage waveform and the power factor is as closeto 1 as possible
⚫ In three-phase AC mode, two access modes are supported: Yand Δ
⚫ Comprehensive harmonics measurement and analysis, up to 50th. Built-in
IEC61000-3-2/3-12 pre-compliance test standard *2
⚫ Support the loading and unloading angle control, the full range of 0-359°
can be set
⚫ Various protection functions such as Protect auto clear (UV&FE auto Clear),
POVP, POCP, UVP, Software watchdog
* 1 After the rectification function is enabled, the setting range of phase shift is restricted by the
peak factor
* 2 Voltage/current harmonic analysis, current harmonic simulation, fundamental wave ≤ 60Hz
1.2 Models and Options
