General Information
8 CENTRON® Meter Technical Reference Guide
Technical Data
Meets applicable standards:
 ANSI C12.1 - 2001 (American National Standard for Electric Meters - Code for
Electricity Metering)
 ANSI C12.18 - 1996 (American National Standard - Protocol Specification for ANSI
Type 2 Optical Port)
 ANSI C12.19 - 1997 (American National Standard - Utility Industry End Device Data
Tables)
 ANSI C12.20 - 2002 (American National Standard for Electricity Meters - 0.2 and 0.5
Accuracy Classes)
 ANSI/IEEE C62.45 - 1992 (Guide to Surge Testing in Low-Voltage AC Power
Circuits)
 IEC 61000-4-2
 IEC 61000-4-4
Dimensions
The following dimensional measurements are shown in inches and (centimeters).
Figure 6: Dimensions
Polycarbonate
A B C D E
6.29
(16.00)
6.95
(17.70)
2.70
(6.90)
3.16
(8.00)
4.53
(11.50)
Glass
A B C D E
6.42
(16.30)
6.95
(17.70)
3.17
(8.10)
3.64
(9.20)
5.01
(12.70)
