Operation: C12.19 C1SD, C1ST, and C1SL Versions
60 CENTRON® Meter Technical Reference Guide
Recording Duration
Use the following equation to determine the recording duration for the load profile register:
)))128/)46(()22((1440/()1024()(
CCIMdaysDuration
M= Memory size in kilobytes
C = Number of channels
I = Interval Length in minutes
Recording Duration (in days) for 144 Kbyte load profile memory size:
Number of
Channels
Interval Length (Minutes)
1 25 50 75
100
125
150
251
301 376 502
753 1506
2 16 33 50
66 83 100
167
200 250 334
501 1003
3 12 25 37
50 62 75 125
150 187 250
375 751
4 10 20 30
40 50 60 100
120 150 200
300 601
5 8 16 25
33 41 50 83 100 125 166
250 500
6 7 14 21
28 35 42 71 85 107 143
214 429
7 6 12 18
25 31 37 62 75 93 125
187 375
8 5 11 16
22 27 33 55 66 83 111
166 333
Optional Features
Event Log
The C12.19 C1SD/T/L register has an Event Log that records historical events that have
taken place in the meter. The events to be logged must be configured via the PC-PRO+
Advanced programming software. To aid in troubleshooting, Itron recommends enabling all
events to be logged.
In order to have date and time associated with an event, Time-of-Use or Load Profile
is required. A Demand-only register allows for event log recording; however, in the
event of a power outage, the date and time will not be reliable.
The C12.19 C1SD/T/L register Event Log is circular in nature, allowing for the capture of
the most recent events in the meter at all times. The register is capable of retaining 420
events prior to wrapping.
Each event log record includes an event description, a time and date stamp, and additional
information on certain events.
