Installing 40W and 50W ERT Modules PUB-0126-001 4/04
01552
Place the ERT module on the
mounting bracket as shown, with
the wires in the remote mounting
bracket cable exit notch..
4-7
4-9
4-8
The ERT module and mounting
bracket should look like this.
4-4
01014
Make sure the register wires are still
positioned in the exit notch.
To Next Page
