Installing 40W and 50W ERT Modules PUB-0126-001 4/04
Specifications for the installation kit
screws used to attach 40W/50W
ABB Scancoder ERT modules to
wood, sheet metal, or masonry
surfaces are given at right. The
screws are shown approximately
actual size.
01787
Remote Mounting Bracket
3 Mounting Screws
2 Plastic Tamper Seals
3 Gel Connectors
2 Cable Ties
NOTE: Configuration kits are shipped in bulk, with 30 kits per box.
Configuration Kit (part number CFG-0067-001)
APPENDIX B. ITRON INSTALLATION KITS
Refer to Water ERT Ordering
Guide (PUB-0063-001) for part
numbers of all components.
10-12 x 1 1/2 Phillips Pan Head Tapping Screw, Corrosion
Resistant Steel
B-1
