Installing 40W and 50W ERT Modules PUB-0126-001 4/04
Push the wires that are to be con-
nected together as far as possible
into the connector.
CAUTION
Do not strip any insulation from
the ends of the wires before you
push them into the connector.
Place the connector (with wires) into
the jaws of the crimping tool.
Crimp the connector by squeezing
the handles until the connector looks
like this. Continue to apply pressure
for three seconds.
00985
00984
00653
00978
A-1
A-2
A-3
A-1
APPENDIX A. CONNECTING CABLE WIRES WITH GEL
CONNECTORS
