Installing 40W and 50W ERT Modules
Specifications for the screws used to attach remote mounting brackets to wood or
sheet metal surfaces are given at right. The screws are shipped in bulk. The
screws are shown here approximately actual size.
10-12 x 1 1/2 Phillips Pan Head Tapping Screw, Corrosion
Resistant Steel
01788
3 Mounting Screws
Remote Mounting Bracket
2 Plastic Tamper Seals
3 Gel Connectors
2 Cable Ties
NOTE: Configuration kits are shipped in bulk, with 30 kits per box.
Refer to Water ERT Ordering Guide (PUB-0063-001) for part numbers of all
components.
4 Remote Mounting
Bracket Screws
B-2
Configuration Kit (part number CFG-0067-002)
