Installing 40W and 50W ERT Modules PUB-0126-001 4/04
Get four T
orx-head mounting
screws
from the bulk supply
. The screws
are shown approximately actual
size.
5-10
Install the
T
orx-head screws
here.
Hand tighten every screw
.
5-5
NOTE
Refer to Section 7 for instructions on how to inst
all the ERT
module to the register
.
5-1
1
28
30
