Installing 40W and 50W ERT Modules PUB-0126-001 4/04
After the plastic tamper seals have been
installed, the ERT module should look
like this.
ERT module on wood or sheet metal surface.
01352
01029F
6-28
6-29
When a tamper seal is fully seated,
the
top of the tamper seal
is about 3/32-inch below the
top of the screw recess.
