INSTALLATION 2
13
SHARPFLOW SWB7 + CWB7
www.itron.comWA-0092.0-EN-qs-06.13
2.8.5 Pump
2.8.6 Control valve
2.8.7 Air venting and vacuum forces
Figure 2-13: Recommended installation: behind a pump
1 Inlet: ≥ 3 DN
Figure 2-14: Recommended installation: in front of a control valve
Figure 2-15: Air venting
1 ≥ 5 m
2 Air ventilation point
