ITRON SHARPFLOW SWB7 - IP68 Rating and Submersion Capabilities

INSTALLATION 2
15
SHARPFLOW SWB7 + CWB7
www.itron.comWA-0092.0-EN-qs-06.13
2.8.9 IP68
The SharpFlow flow sensor is rated IP68 (NEMA 4X/6P). It is suitable for submersion in flooded
measurement chambers and for subsurface installation.
The compact SharpFlow CWB7 signal converter is available in:
• a polycarbonate housing suitable for IP68, NEMA 4/4X/6.
This version is suitable for periodic submersion in flooded measurement chambers. The
output cable has IP68 rated (military) connectors.
In case of continuous or long term submersion it is advised to select the field (remote)
version (IP66/67). Submersion under water is possible down to a depth of 5 meters.
The remote SharpFlow CWB7 signal converter is available in:
• an aluminium housing suitable for IP66/67, NEMA 4/4X/6.
Figure 2-18: IP68 versions
1 Submersible
2 Buried
12
