2 INSTALLATION
18
SHARPFLOW SWB7 + CWB7
www.itron.com WA-0092.0-EN-qs-06.13
Nominal size
[inches]
Flange class
[lb]
Bolts Max. torque
[lbs.ft]
1
1 150 4 x 1/2" 4
1½ 150 4 x 1/2" 11
2 150 4 × 5/8" 18
2.5 150 8 x 5/8" 27
3 150 4 × 5/8" 33
4 150 8 × 5/8" 22
5 150 8 × 3/4" 33
6 150 8 × 3/4" 48
8 150 8 × 3/4" 66
10 150 12 x 7/8" 74
12 150 12 x 7/8" 106
14 150 2 12 × 1" 87
16 150 2 16 × 1" 84
18 150 2 16 × 1 1/8" 131
20 150 2 20 × 1 1/8" 118
24 150 2 20 × 1 1/4" 166
1 The torque values also depend on variables (temperature, bolt material, gasket material, lubricants, etc.)
outside the control of themanufacturer. Therefore these values should be regarded as indicative only.
2 No full rating (max. 145 psi).
