Pancode VoIP/Pantel VoIP Access Control Door Phones
Installation and Programming Manual
7.1 Analog Video Camera Technical Specification
Black and White Video Camera
Model number MK-03261C
TV System EIA/CCIR
Image Sensor Device 1/3” interline transfer CCD
Image Sensor Area 4.8mm x 3.6mm
Horizontal Frequency 15.625KHz
Vertical Frequency 50Hz
Total Pixels 542(H) x 582(V)
Scanning System 625 lines, 50 fields/sec CCIR
Resolution 420 TVL horizontal
Minimum Illumination 0.5 Lux at F2.0
Electronic Shutter Auto Electronic Shutter 1/50 to 1/100000 sec. Continual
S/N Ratio Better than 48 dB
Video Signal Output 1.0Vp-p composite video signal at 75 ohm load
Gamma Correction 0.45
Gain Control Auto Gain Control (AGC)
Lens & View Angle 5.5 mm F5.5 / 60°
Color Video Camera
Model number MTV-54KOPI
TV System PAL/NTSC
Image Sensor ¼-inch CCD Image Sensor
CCD Total Pixels 542(H) x 586(V)
SYNC System Internal
Minimum Illumination 0.5 Lux F1.2 5600°K
Resolution 380 TVL/470 TVL (Enhanced)
S/N Ratio 52dB (MIN)/60dB(TYP) (AGC OFF)
White Balance ATW/AWB/FIX (Zero color rolling)
White Balance Range AWB, ATW (3200---10000°K) /FIX(3299°K)/
Electronic Shutter 1/50-1/120000 sec.
Video Output 1.0Vp-p composite video signal at 75 ohm
Gamma Correction 0.45
Gain Control AGC
Lens & View Angle 45° > 0.7 mm
45
