Pancode VoIP/Pantel VoIP Access Control Door Phones
Installation and Programming Manual
7. Technical Specification
Power supply 12V AC; 1.5A or Power Over Ethernet IEEE 802.3af compliant
12 V DC 3A – for devices with the video over IP option ( Analog camera
and internal video web-server)
Power Consumption
1. Without analog video camera and AV server card: 3.6W
2. With analog video camera and AV server card: 7.2W
Note: The Maximum power consumption (short) pick value may be up to
30% higher then listed below.
Communication interface Ethernet for voice; and for programming
DC Leakage <10 µA
Imbalance ratio 300-3400Hz > 46dB
Return loss 300-3400Hz > 18dB
Relay switching current 2A max
VoIP protocol supported SIP; RTP; RTCP
Supported codecs G.711 PCM (µ/A-Law) at 64 kbps
Echo canceller
G.168-2002 Compliant with programmable echo tail of up to 128 msec.
Full duplex, acoustic EC
Quality Enhancement Comfort Noise generation (CHG)
Packet Loss Concealment (PLC)
Adaptive Jitter Buffer(up to 300 msec)
Echo canceller length Up to 64 msec
IP media features Automatic Gain Control
In-Band Signaling Detection and
Generation
DTMF TIA464B
Dimensions 19.4 X1 0.2 cm
Dimensions Flush Mounted Unit
Flush Panel:13.8 x 23.3cm / 5.4 x 0.9 inch
Flush Mounted part:9.8 x 19 x 2.5 cm/3.8 x 7.5 x 0.9 inch
Weight 0.9 kg
Operating temperature 0ºC to +55ºC / 32ºF to 131ºF
0ºC to +35ºC / 32ºF to 95 ºF with analog video camera
0ºC to +30ºC / 32ºF to 86 ºF, including analog video camera and A/V IP
video server card
44
