Pancode VoIP/Pantel VoIP Access Control Door Phones
Installation and Programming Manual
4.1.2 Installing the IP Networking Video Camera
Device accomplished with the IP (Video over IP) internal video camera
and internal video web-server supplied with the 12 V DC external
power supply. Check the power supply connections polarity. Incorrect
connectivity can destroy device. (See Figure
4-2 )
1. Existing IP Door units can be supplied with the analog video camera and internal web-
server.
2. Customer takes full responsibility on the video camera functionality in case when the
third part IP networking video camera will be used with the door units.
3. IP video camera functionality depends on the Pancode / Pantel VoIP hardware’s
release in case when the unit powered by using the POE technology. Apply to your
local dealer in order to check the hardware compatibility.
The Pantel VoIP/Pancode VoIP unit provides the video stream via the TCP/IP based network.
In order to provide the video stream over TCP/IP based network Pancode / Pantel IP must
be accomplished with the Video Camera and Internal Network Server.
Especially network server generates an MPEG4 video at different resolutions, allowing for high quality
monitoring while recording at a different image rate maximizing storage and transmission efficiency. In addition
to network server supports DirectX 9.0 supporting viewer, which enable PC CPU resources to drop.
The Pantel VoIP/Pancode VoIP unit can be installed with an internal video camera. The video camera 12V DC
power is supplied via the 11 and 12 pins located on the Main PCB Connector (see Figure
4-9 Internal IP Camera
connections ). In addition to the internal or external IP video camera can be powered with the own external
power supply.
The internal video camera can be physically installed on the ‘Internal video camera installation’ place (see Figure
4-9 Internal IP Camera connections ). Camera’s video output internally connected with the network video web-
server which connected with the RJ-45 Port 1 socket by the Network bridge-cable. The video camera is
constantly transmitting images using an analog video stream.
