Pancode VoIP/Pantel VoIP Access Control Door Phones
Installation and Programming Manual
5.2 Scanning for a Device in the Network
When the unit MAC address is unknown, it is possible to find an existing device in the network using the SCAN
utility from the installation CD.
SCAN utility required for any OS Windows based network capturing
utility installation. For example: The Wireshark utility which can be
downloaded from the link http://www.wireshark.org/download.html
To find a device in the network:
a. Insert the installation CD and copy the scan.exe file from the Software directory to the local hard drive.
b. Disconnect the Pancode VoIP/Pantel VoIP from the external power supply.
c. Start MS Windows DOS prompt application.
d. Access the directory, in which the scan.exe application exists.
e. Enter the following command: scan + <Enter>. A scan takes place, at the end of which the installed PC
Ethernet adaptor appears (Figure
5-).
Figure 5-3. Searching for Device in the Network
f. Select the required Ethernet adaptor.
g. Press Enter.
h. Switch On the power! A scan for the device takes place, at the end of which the detected Pancode/Pantel
device IP information, including MAC address and network settings, appears (Figure
5-).
Figure 5-4. Search Results for Device in the Network
32
