Pancode VoIP/Pantel VoIP Access Control Door Phones
Installation and Programming Manual
Parameter Description
TFTP Server IP address
An identifier for the TFTP server on a TCP/IP network, where configuration
files will be stored. The TFTP server can be activated by using the Third Part
Company tftp software. For example: Tftpd32 application, which can be
found on the following URL:
http://www.snapfiles.com/download/dlTftpd32.html )
Configuration File name
Previously saved configuration file name, which has to be written here and
IP Door Panel will upload it using tftp server settings.
Firmware file name
Internal IP Door Panel Firmware file name. Uploading procedure is the
same as Configuration file.
Kernel File name
Internal IP Door Panel Kernel file name. Uploading procedure is the same
as Configuration file. This parameter may be changed by a qualified
and authorized person only!
Software Version
Displays the IP Door panel internal software number.
Hardware Version
Displays the IP Door panel internal hardware edition number.
5.5 VoIP Dialing settings
The VoIP Dialing Parameters screen displays the dialing and door opening definitions.
Pancode VoIP has two dialing modes: standard and sped-dial. Pantel
VoIP has the standard mode only.
The VoIP Dialing screen contains the following areas:
Parameter Name and Parameters area:
Parameter Description
DTMF SIP Presentation mode
Defines the mode of providing DTMF tone information in the SIP VoIP
network. Possible choice: RFC 2833 or Transparent (In-Band DTMF).
Speed Access Codes 1 to 10
Access Door Opening Codes (speed-dial mode) fields – contain door-
opening codes in speed-dial mode. Each field can contain a code of up to
8 digits, which opens the door lock. Legal entries: 0-9 digits only. All codes
in this mode must start with 0.
38
