i-ALERT2 Application Guide 13 of 64
DEVICE OVERVIEW
The i-ALERT2 Equipment Health Monitor is a compact, battery-operated monitoring device that continuously measures the
vibration and temperature of a piece of rotating equipment. The i-ALERT2 Equipment Health Monitor uses blinking red LED
and wireless notification to alert operators when the equipment exceeds vibration and temperature limits. This allows the
operator to make changes to the process or the equipment before catastrophic failure occurs. The Equipment Health
Monitor is also equipped with a single green LED to indicate when it is operational and has sufficient battery life.
The i-ALERT2 Equipment Health Monitor also contains a Bluetooth radio that communicates to certain Bluetooth 4.0
equipped devices through a mobile application. Data is shared between the i-ALERT2 Equipment Health Monitor, the
mobile application, phone, and the data servers.
The i-ALERT2 Equipment Health Monitor will communicate sensor related data (such as vibration, temperature, runtime
information, and device statistics) stored in the device to the mobile application. The mobile application will send
commands to the device.
The Mobile application will back up device data as well as app usage information on the data servers.
The data servers will send the mobile application equipment technical data. For full details about data storage and rights
please review the Privacy Policy.
The i-Alert2 may use Version 1 or Version 2 firmware. To determine which version you have, in the App go to “Equipment
Info, i-ALERT Information” where the device version number will be shown., Alternatively, for the Version 2 units, the
sticker on the back of the device will have a manufacturing date after 8/22/2016.
Alarm mode
The i-ALERT2 Equipment Health Monitor enters alarm mode when either vibration or temperature limits are exceeded over
two consecutive readings within a 10 minute period. Alarm mode is indicated with 1 (one) red flashing LED within 2 (two)
second intervals.
Warning and Alarm Values Variable
Vibration Alarm (0.1-1.5 ips)
100% increase over the baseline level
Vibration Warning (0.1-1.5 ips)
75% increase over the baseline level
VIBRATION AND TEMPERATURE SPECIFICATIONS
• Axial / Horizontal Sensor Frequency Range 10 Hz to 1000 Hz
• Radial Sensor Frequency Range 10 Hz to 600 Hz
• 15g Dynamic Range
• Spectral vibration measurements have a frequency bandwidth resolution of 1 Hz.
• Amplitude accuracy +/- 10%
• Diagnose machine faults with vibration tools Fast Fourier Transform & Time Waveform analysis
• Maximum temperature of 183°F
TRENDING SPECIFICATIONS
• Sensors and onboard memory tracks vibration, temperature, & run-time hours continuously
• Devices checks every five minutes & alarms if equipment is outside normal operating conditions
• Stores overall RMS trend data once per hour & on alarm for 60 days (Version 1) or 170 days (Version 2)
• Stores the weekly average, minimum & maximum up to 5 years
• Calculates and stores Kurtosis values
Table 1: Default Alarm Values
