I-FRAME PUMP
On any ITT Goulds Pumps that come equipped with the i-ALERT2 device, a slot will be machined in the bearing housing to
mount the device within close proximity to both bearings. See figure 12.
Figure 12: ITT Goulds 3196 i-FRAME contains milled slot for mounting the monitor
