MONITOR DESCRIPTION
Model 3000T Operation Manual
8
MONITOR DESCRIPTION
The Model 3000T Cardiac Trigger Monitor, which is based on the model 3000 series, is an easy to use color
monitor that display a patient’s ECG waveform and heart rate. The ECG lead displayed can be selected from Leads
I, II or III. In addition high and low heart rate alarm limits can be adjusted to bracket the patient’s heart rate so that a
violation of these limits produces an audible and visual indication of the violation. The color display has a single
trace, large Heart Rate numbers and alphanumeric characters for other data, alarm messages, menus and user
information.
The Model 3000T monitor is intended primarily for use on patients in applications requiring precision R-wave
synchronization such as timed imaging studies.
The Model 3000T-B has a USB drive that allows the operator to store and retrieve ECG data on a USB memory
stick device. The Model 3000T-B also has special hardware and software that allows for the measurement of ECG
electrode impedance, prior to, and after the CT scan.
An integral recorder is optional on the Model 3000T, set up of recorder functions are made through the monitor
menus.
The Model 3000T is suitable for use in presence of Electro-surgery.
The Model 3000T is not intended for use with any other physiological monitoring unit.
The Model 3000T is restricted to use on one patient at a time.
The Model 3000T is not intended for home-care patient monitoring.
Summary of main options__________________ _____
Model 3000T-A Model 3000T-B
Strip Recorder Optional Optional
Polarity Lock (P-Lock)
* *
Wide ECG trace
* *
Trigger Mark
* *
Impedance Measurement
*
USB Drive
*
* = available
