MONITOR DESCRIPTION
Model 3000T Operation Manual
9
Intended Use
The Ivy Biomedical Model 3000T Patient Monitor is a simple to use instrument for monitoring the ECG and Heart
Rate. It is designed for use in the ICU, CCU and operating room conditions. It can sound an alarm when the HR
falls outside of preset limits. It provides an output pulse, synchronized to the R-wave for use in applications
requiring precision R-wave synchronization.
The Model 3000T is limited to use by trained and qualified medical professionals. This product is not intended for
home care monitoring.
Classification (in accordance with IEC-60601-1)
Protection against electric shock: Class 1.
Degree of protection against electric shock: Type CF applied part. Defibrillator proof: ECG
Degree of protection against harmful ingress of water
Ordinary equipment: IPX0 per IEC-60529
Methods of Maintenance and Cleaning: See page 33
Degree of safety of application in the presence of a
flammable anesthetic mixture with air or with oxygen Equipment not suitable for use in the presence of a
or nitrous oxide: flammable anesthetic mixture
Mode of operation: Continuous
Controls and Indicators
Basic Keys
When the monitor is plugged into an AC power source the ON switch, when pressed, provides power to
the monitor’s electronic circuits.
The STBY switch, when pressed, disconnects power from the monitor’s electronic circuits.
NOTE: To disconnect the monitor from the main power unplug the AC power cord.
Disables the audible and visual alarms for a two-minute period to allow the operator perform procedures
that would otherwise set off the alarms. This avoids the problem of turning off the alarms and forgetting
to turn them back on. Press this key again to return the alarms to normal before the two minutes have
expired. Pressing ALARM PAUSE key for 3 seconds will turn alarms off. Press ALARMS PAUSE key
again to reactivate the alarms. Pressing ALARM PAUSE key will pause the alarms for 120 seconds (2
minutes).
