TROUBLESHOOTING
32 Model 3000T Operation Manual
TROUBLESHOOTING
Problem Verify that:
 Unit does not turn on.
 Power cord is plugged into the monitor and the AC outlet
.
 Line Voltage selector is in the appropriate position.
 Fuses are not blown.
 The ON switch is pressed.
 Trigger pulse is not functional
 The Auxiliary port connector is plugged into the monitor.
 ECG size is optimal (select Lead II)
 Erratic ECG waveform. Heart Rate is
not counting.
 ECG waveform has enough amplitude (Select Lead II).
 Electrodes placement (see ECG section for proper
placement diagram).
 ECG electrodes have enough conductive gel.
