Set communication between PC and HDBaseT
receiver.
① Y is for RS232 port (connect with
RS232 port of HDBaseT receiver)
The value of Y is defined into the
following meanings (in a given baud
rate depended by the value of X):
a. Y = 1~8, send this command to the
corresponding HDBaseT receiver to
control far-end device.
b. Y = 9, send this command to all
HDBaseT receivers to control all
far-end devices.
c. Y = A~H, under PWON mode, send
this command to the corresponding
HDBaseT receiver to control far-end
device.
d. Y = a~h, under PWOFF mode, send
this command to the corresponding
HDBaseT receiver to control far-end
device.
② X is for baud rate, its value ranges
from 1 to 7 (1--2400, 2--4800,
3--9600, 4--19200, 5--38400,
6—57600, 7--115200)
③ ***** is for data (max 48 Byte)
