Control Far-end Device Commands
%9944.
Under PWOFF mode, check the command
which was sent from port 4 to far-end
device.
Port 4: ********
when PWOFF
%9945.
Under PWOFF mode, check the command
which was sent from port 5 to far-end
device.
Port 5: ********
when PWOFF
%9946.
Under PWOFF mode, check the command
which was sent from port 6 to far-end
device.
Port 6: ********
when PWOFF
%9947.
Under PWOFF mode, check the command
which was sent from port 7 to far-end
device.
Port 7: ********
when PWOFF
%9948.
Under PWOFF mode, check the command
which was sent from port 8 to far-end
device.
Port 8: ********
when PWOFF
CEC Commands (These commands below are shown for reference only)
43 45 43 01
36 2E
Turn off the display devices.
43 45 43 01
44 6C 2E
43 45 43 01
04 2E
Turn on the display devices.
43 45 43 01
44 6D 2E
43 45 43 01
44 41 2E
Volume up
43 45 43 01
44 42 2E
Volume down
RS232 CONTROL COMMANDS
