JAC J2 User Manual



Maintenance Manual for J2 Sedan
Mechanical Part of Engine
99
3)
Dismount
oil
pan.
a.
First,
use
loosening agent
for
sealants in order
to prevent oil pan sealing surface from
deformation.
b.
Loosen
the
fixed
bolts
accordin
g
to
following
sequence: center-both sides.
■
Tightening
torque:7.6±0
.6
N·m
c.
Knock
the
special
tool into the
space
between
oil pan and cylinder body as shown in Fig.
1.2.008.
d.
Slightly knock
the
side
of
special
tool,
in
order to make the tool move along the sealing
surface of oil pan/cylinder body, and then
dismount the oil pan.
Attention:
■
Do
not
damage the
matching
surface.

4)
Dismount
oil
pump
housing
assembly.
5)
Dismount
oil
pickup.
Attention:
■
Tightening
torque:
8.4±0.65
N·m
3.
Check
after
Dismantlement
1)
Oil
pickup
■
Remove
any attached foreign
bodies
of
oil
pickup.
2) Oil pump housing
assembly
■
Check the
oil
hole of
oil pump
casing assembly
for blockage, and
clean
it
if necessary
.
■
Check the
oil
pump c
asing assembly for
crack or
other damage.
If there
is any
, please
replace.
3. Installation
1) Install oil filter set.
2)
Install
pump
housing
assembly.
3) Install external generator, power steering pump, cylinder head
cover and
other parts on the oil
pump
Fig. 1.2.007
Fig. 1.2.008
Fig. 1.2.009
