Maintenance Manual for J2 Sedan
Electrical Part of Engine
152
1) Disassembly
Disassemble in the following order.
①

Belt
pulley
②

Rear
cover
③
 Commutator
assembly
④

Separate
front and
rear
cover
assembly.
Attention:
■
Be
careful
to
avoid
damage
of
stator
assembly
.
2) Check after
disassembl
y
①
 Inspect of rotor
a.
Resistance
test
Resistance: Approximately 2.0-2.5 Ω
■ If it is
beyond
the
standard range, replace.
b. Insulator
test
■
If
electrically
continued,
replace.
c.
Inspect
wearing
condition of slip ring.
■ If it is beyond
the
standard range,
replac
e.
②

Carbon
brush
a.
Check
carbon
bush
for
smooth
moving.
■
If not, ins
pect
carbon
brush sup
port and
clean
as required.
b.
Check
wearing
condition
of
carbon
brush.
■ If
Limit
is exceeded, replace brush.
Fig. 3.2.021
Fig. 3.2.022
Slip ring
The mark line of
wearing limit of
electric brush
