JAC J2 User Manual



Maintenance Manual for J2 Sedan
Electrical Part of Engine
153
③
 Stator
a. Inspect continuity between terminals.
■ If not,
replace.
b. Grounding test
■
If
electrically
continued,
replace
the
stator.
3) Assembly
①

Rear
bearing
Attention:
■ The rear
bearing can
not be r
eused after
being taken
off. Please
with new
one.
■
Lubrication
of rear
bearing
out race is not
permitted.
②

Installati
on
of
rear cover
a.
Mount
the carbon
brushes
assembly, adjuster
assembly and stator.
b.
Push the
carbon brushes
with fingers
to install them
on
the
stator.
Attention:
■
Be
careful
to
avoid
damage
of
slip
ring
surface.
Fig. 3.2.025
Fig. 3.2.024
Fig. 3.2.023
Lead
Lead
Stator
core
