weight is nearest to the
calculated value, and install it to the specified outer side position, or at the
specified angle relative to wheel.
Attention:
■ The balance block of outer side should be installed before inner side.
■
Prior to
the installation
of balance
block, fitting
surface
on w
heel must
be thoroughly
cleaned.
a. Install th
e b
alance block to the
position
indicated
in f
igure b
elow.
b.
As sho
wn i
n the
figure,
during
installation
of
balance block on the wheel, the balance block
should be placed in the groove area on the
wheel
inner wall, and fix
with
its center
towards the position (or angle) indicated by
the wheel balancer.
Attention:
■
The
balance
block
should
not be
reused;
it s
hould
be
replaced
every
time.
■
At mos
t
three
balance blocks are allowed
to
be installed.
■
The
original
balance
blocks
should
be
used
any
time.
c.
In
case
the
calculated
weight
of
balance
block
is more than 50 g, the two balance blocks
should be installed in a line.
Attention:
■ Never install
a
balance block on another
one.
③

Restart the
wheel
balancer.
④

At pos
ition (or angle) indicated by the
wheel
balancer, knock in the balance block at the
inner side of wheel.
Attention:
■
At mos
t
two
balance blocks are allowed to be installed.
⑤

Start the balan
cer. Make s
ure the residual
unbalanc
e value of b
oth inner side
and outer side
is only
5 g or less.
■
In case
the residu
al unb
alance
value o
f either
side i
s more
than 5
g, pleas
e repea
t the
installation
steps for balance block.
Fig. 2.2.010
Fig. 2.2.011
Stuck weight
Towards the
groove
Position (or angle) indicated
by the wheel balancer
Center of gravity
Position (or angle) indicated
by the wheel balancer
