Jackson Systems T-32-TS Installation Manual

SETTING THE SYSTEM SWITCHES
The T-32-TS contains a set of four system switches located on the thermostat
printed circuit board. (Figure 3) The switches are used to match the thermostat
operation and relay outputs with the HVAC system requirements. Refer to the
system switch functions on the next page to properly configure the thermostat.
FIGURE 3
9
1 2 3 4
ON DIP
SYSTEM SWITCHES
. . . . .. . . . . ..
