REMOTE SENSOR INSTALLATION
41
TEMPERATURE/RESISTANCE CHART
Temperature Resistance Temperature Resistance
(°F) (K ) ( F) (K )ΩΩº
30 34.6 70 11.9
40 26.1 80 9.4
50 19.9 90 7.4
60 15.3 100 5.9
NTC type 2 sensor - 10K @ 77° FΩ
