INSTALLER SETUP MENU
ASSIGNING AUXILIARY CONTACTS
Menu 05 assigns the auxiliary dry relay contacts (AUX) as Normally Open or
Normally closed when the Programmable Fan Option 04 is ON. Whenever
Programmable Fan is in the mode (constant ventilation) for aAlways On
selected program period, the relay contact will go open or closed based on the
auxiliary relay option selection. The auxiliary contacts can be used for controlling
an economizer or other IAQ devices. The factory default is .1
1 = Relay contacts closed when Programmable Fan is ON (Factory Default)
2 = Relay contacts open when Programmable Fan is ON
E
Back
Next
26
