Jackson Systems T-32-TS Installation Manual

TESTING
44
Note: On a call for cooling, the thermostat activates a 3 minute time delay before
the cooling relay ‘Y1’ is energized. will flash to indicate the thermostat is inMode
time delay. After the time delay, the internal fan ‘G’ and cooling relay ‘Y1’ will
energize. The word will flash. If the thermostat has been configured for twoCool
stage cooling, lower the setpoint below the second stage differential and Cool 2
will flash indicating the ‘Y2’ cooling relay is energized. Touch until the wordMode
OFF is displayed.
CONVENTIONAL HEAT PUMP
When the T-32-TS is configured for conventional heat pump operation, testing is
the same as a heating and cooling system with the exception that a 3 minute
time delay is activated before the ‘Y1’ compressor relay will energize on a call for
heating or cooling. will flash to indicate the thermostat is in time delay.Mode
Depending on the mode of operation and equipment configuration, orHeat Cool
will flash when the ‘Y1’ compressor relay is energized. or will flashHeat 2 Cool 2
when the ‘Y2’ compressor relay is energized. will flash when theHeat 2 3
auxiliary ‘W1’ relay is energized. will flash when the mode is set toE.Heat
emergency heat. After testing, touch until the word is displayed.Mode OFF

Jackson Systems T-32-TS Specifications

General

Brand	Jackson Systems
Model	T-32-TS
Category	Thermostat
Language	English
