Jackson TempStar Series - SPECIFICATIONS; MACHINE DIMENSIONS

SPECIFICATIONS
DIMENSIONS (TOP MOUNT CONTROL BOX)
4
25 [637mm]
73 1/4 [1873mm]
34 [861mm]
27 [686mm]
25 1/4 [641mm]
3 [76mm]
1 [25mm]
11 3/4 [298mm]
15 1/4 [387mm]
73 [1856mm]
86 3/4 [2203mm]
17 [432mm]
3 [76mm]
4 [102mm]
4 [102mm]
A
A
B
B
B
C
LEGEND
A - Drain 1 1/2" IPS
B - Water Inlet 3/4" IPS
C - Electrical Connection
All vertical dimensions are +/- 1/2" due
to adjustable bullet feet.
