Jackson TempStar Series Installation, Operation & Service Manual

ELECTRICAL REQUIREMENTS
SPECIFICATIONS
3
NOTE: Typical Electrical Circuit is based upon (1) 125% of the full amperage load of the machine and (2) typical
xedtrip circuit breaker sizes as listed in the NEC 2002 Edition. Local codes may require more stringent protection
than what is displayed here. Always verify with your electrical service contractor that your circuit protection is
adequate and meets all applicable national and local codes. These numbers are provided in this manual simply
for reference and may change without notice at any given time.
Volts Phase Freq
Rinse Heater
Ratings
Total Amps
Typical Electrical
Circuit
415 3 60 12kW 28A 35AMP
415 3 60 14kW 30A 40AMP
208 1 60 12kW@240V 75A 100AMP
208 1 60 12kW@240V 82A 110AMP
230 1 60 12kW@240V 81A 110AMP
230 1 60 14kW@240V 90A 125AMP
208 3 60 12kW@240V 48A 60AMP
208 3 60 14kW@240V 52A 70AMP
230 3 60 12kW@240V 52A 70AMP
230 3 60 14kW@240V 57A 80AMP
460 3 60 12kW@480V 24A 30AMP
460 3 60 14kW@480V 26A 35AMP
TEMPSTAR HH:
Volts Phase Freq
Rinse Heater
Ratings
Total Amps
Typical Electrical
Circuit
208 1 60 N/A 31A 35AMP
230 1 60 N/A 33A 35AMP
208 3 60 N/A 23A 25AMP
230 3 60 N/A 24A 35AMP
460 3 60 N/A 10A 15AMP
TEMPSTAR HH NB & TEMPSTAR HH LT:
Volts Phase Freq
Rinse Heater
Ratings
Total Amps
Typical Electrical
Circuit
208 1 60 N/A 12A 15AMP
230 1 60 N/A 12A 15AMP
208 3 60 N/A 12A 15AMP
230 3 60 N/A 12A 15AMP
TEMPSTAR HH S:

Jackson TempStar Series Specifications

General

Model	TempStar Series
Voltage	208-240V
Number of Wash Cycles	1
Color	Stainless Steel
Category	Dishwasher
Voltage Options	208V, 240V
Capacity	60-80 racks per hour
Water Consumption per Cycle	0.5-1.0 gallons
Water Consumption per Rack	0.84 gallons
