Jackson TempStar Series Installation, Operation & Service Manual

INSTALLATION & OPERATION
14
VENTLESS HEAT RECOVERY MOUNTING INSTRUCTIONS
5
Locate the wire connectors at the top of the unit and connect the white and black wires from the
base unit.
Slide wire into the hole and push the lever down
Tidy up the wires and lock them in place with the P-Clamp on the top of the unit.
P-Clamp
Now you have a fully assembled unit.

Jackson TempStar Series Specifications

General

Model	TempStar Series
Voltage	208-240V
Number of Wash Cycles	1
Color	Stainless Steel
Category	Dishwasher
Voltage Options	208V, 240V
Capacity	60-80 racks per hour
Water Consumption per Cycle	0.5-1.0 gallons
Water Consumption per Rack	0.84 gallons
