Jackson TempStar Series Installation, Operation & Service Manual

HOOD ASSEMBLY
PARTS
31
ITEM QTY DESCRIPTION PART NUMBER
1 1 Hood Weldment 05700-003-05-67
2 2 Hood Support Assembly 05700-004-13-45
3 1 Left Back Inner Door Guide 05700-031-76-34
4 1 Right Back Outer Door Guide 05700-031-76-32
5 1 Right Back Inner Door Guide 05700-031-76-35
6 1 Left Back Outer Door Guide 05700-031-76-33
7 34 Locknut, 1/4-20 Hex w/Nylon Insert 05310-374-01-00
8 26 Washer, S/S 1/4-20 I.D. 05311-174-01-00
9 6 Screw, 1/4-20 x 5/8 S/S Hex Head 05305-274-24-00
10 20 Bolt, 1/4-20 x 1/2 Long 05305-274-02-00

Jackson TempStar Series Specifications

General

Model	TempStar Series
Voltage	208-240V
Number of Wash Cycles	1
Color	Stainless Steel
Category	Dishwasher
Voltage Options	208V, 240V
Capacity	60-80 racks per hour
Water Consumption per Cycle	0.5-1.0 gallons
Water Consumption per Rack	0.84 gallons
