CANTILEVER ARM/DOOR ASSEMBLIES
PARTS
33
ITEM QTY DESCRIPTION PART NUMBER
14 4 Bolt, Cantilever Hanger Eye 3/8"-16 05306-956-05-00
15 4 Washer, Impeller 05311-176-02-00
16 8 Nut, 3/8"-16 S/S Hex 05310-276-01-00
2 Door, Upper, Left & Right Assemblies (not shown) 05700-002-01-30
17 2 Door, Upper, Left & Right Weldment 05700-002-29-59
18 4 Glide, Upper Door 05700-002-00-83
1 Door, Lower, Right Assembly (not shown) 05700-002-01-33
19 1 Door, Lower, Right 05700-004-14-18
20 2 Glide, Lower Door 05700-002-23-64
21 1 Door Stop Magnet Assembly 06401-003-08-68
1 Door Stop Magnet Weldment (not shown) 05700-002-01-27
1 Magnet (not shown) 05930-111-69-25
2 End Cap (not shown) 05700-011-60-92
22 6 Bumper, Tempstar HH Door 05700-004-14-25
23 12 Screw, 1/4"-20 x 5/8" 05305-274-24-00
24 12 Locknut, 1/4"-20 S/S Hex with Nylon Insert 05310-374-01-00
25 2 Screw, 1/4"-20 x 1/2" Long Hex Head 05305-274-02-00
26 2 Spacer, PB Bolt 05700-000-29-40
27 2 Bracket, Door Connector 05700-004-14-24
28 1 Handle, Front Door Weldment 05700-004-14-30
1 Door, Lower, Front Assembly (not shown) 05700-002-01-31
29 1 Door, Lower, Front 05700-004-14-22
30 2 Glide, Upper Door 05700-002-23-64
1 Door, Upper Front Assembly (not shown) 05700-002-24-92
31 1 Door, Upper, Front Weldment 05700-002-29-57
32 2 Glide, Upper Door 05700-002-00-83
1 Door, Lower, Left Assembly (not shown) 05700-002-01-32
1 Door, Lower, Left Assembly (Door Lock) (not shown) 05700-004-24-21
33 1 Door, Lower, Left 05700-004-14-20
1 Door, Lower, Left (Door Lock) (not shown) 05700-004-24-22
1 Door Interlock Bracket (not shown) 05700-004-23-17
34 2 Glide, Lower Door 05700-002-23-64
35 6 Door Stop Weldment 05700-002-29-60
36 1 Door Stop 06401-003-08-69
To Next Page
