Jackson TempStar Series Installation, Operation & Service Manual

PARTSPARTS
TEMPSTAR HH VENTLESS HEAT REVOCERY SYSTEM ASSEMBLY
ITEM QTY WasherDESCRIPTION PART NUMBER
1 1 Coil, Heat Exchanger 04420-004-19-61
2 1 Inlet, Cold Water 05700-004-19-01
3 1 Ring, Water Inlet 05700-004-19-24
4 1 Plate, Fan Mounting 05700-004-18-07
5 1 Upper Shroud 05700-004-18-06
6 1 Exhaust Box 05700-004-18-04
7 1 Gasket, Heat Exchanger 05330-004-18-22
8 1 Gauge 06680-011-86-42
9 1 Coil Box Back 05700-004-18-03
10 12 Bolt, 1/4-20 X 3/8 Hex 05305-274-20-00
11 1 Bracket, Vacuum Breaker 05700-004-18-91
12 1 Shroud, Hear Exchanger 05700-004-18-92
13 6 Nut, Lock 10-24 S/S Hex w/ Nylon 05310-373-01-00
14 6 Washer, Flat 05311-173-02-00
15 2 Fan, 3.62 Square, 85-236V AC Corrosion Resistant 05999-004-19-46
16 8 Screw, 6-32 X 1 1/2 Long 05305-003-11-33
17 4 Nut, Lock 1/4-20 Hex Nylon Insert 05310-374-01-00
57

Jackson TempStar Series Specifications

General

Model	TempStar Series
Voltage	208-240V
Number of Wash Cycles	1
Color	Stainless Steel
Category	Dishwasher
Voltage Options	208V, 240V
Capacity	60-80 racks per hour
Water Consumption per Cycle	0.5-1.0 gallons
Water Consumption per Rack	0.84 gallons
