Jackson TempStar Series Installation, Operation & Service Manual

v
TABLE OF CONTENTS
SCHEMATICS
Solid State (Top Mount Control Box) 208-230V, 50/60Hz, Single/Three Phase .......................... 60
Tempstar HH (Universal Timer) 208-230V, 50/60Hz, Single/Three Phase .................................. 61
Solid State (Top Mount Control Box) 460V, 60Hz, Three Phase ................................................. 62
Tempstar HH (Universal Timer) 460V, 60Hz, Three Phase ......................................................... 63
Tempstar HH S (Universal Timer) 208-230V, 50/60Hz, Single/Three Phase .............................. 64
Tempstar HH 208-230V, 50/60Hz, Single/Three Phase .............................................................. 65
Tempstar HH 460V, 60Hz, Three Phase ..................................................................................... 66
Tempstar HH S 208V-230V, 60HZ, Single/Three Phase ............................................................. 67
Tempstar HH, NB 208/230V, 50/60Hz, Single Phase .................................................................. 68
Solid State Tempstar HH, NB/LT 208-230V, 50/60Hz Single Phase ........................................... 69
SDI Option ................................................................................................................................... 70
Exhaust Fan Hookup/Drain Quench Options .............................................................................. 71

Jackson TempStar Series Specifications

General

Model	TempStar Series
Voltage	208-240V
Number of Wash Cycles	1
Color	Stainless Steel
Category	Dishwasher
Voltage Options	208V, 240V
Capacity	60-80 racks per hour
Water Consumption per Cycle	0.5-1.0 gallons
Water Consumption per Rack	0.84 gallons
