101
> Change from previous revision
LIGHTWEIGHT FAIRWAY MOWER
Item Part No. Qty. Description Serial Numbers/Notes
1
445525 2 Palnut, 1/4
2 445795 2 Nut, 5/16-18 Spiralock Flange
3 1002226 2 Zerk Bolt
4 3004738 2 Front Roller Adjuster
5 4388406 1 Shield Assembly
6 3009280 1 Scraper, 22” Rear Roller
7 3009281 1 Spring, 22” Rear Roller Torsion
8 343616 2 Stud
9 352737 2 Screw, 1/4-20 x 7/8” Square Head
10 2000135 1 Counter Balance
11 3005692 2 Knob, Roller Adjusting
12 441674 2 Carriage Bolt, 5/16-18 x 1-3/4”
13 443102 6 Nut, 1/4-20 Hex
14 3006022 2 Pin
15 446130 2 Lock Washer, 1/4 Heavy
16 3006021 1 O-Ring
17 400264 2 Screw, 3/8-16 x 1-1/4” Hex Head
18 446142 2 Lockwasher, 3/8 Heavy
19 453011 4 Flat Washer, 3/8
20 403782 2 Screw, 1/4-20 Hex Flange
21 4388410 1 Handle, Shield
22 3006290 2 Bushing
23 453023 2 Flat Washer, 1/4
24 1003728 1 Rear Roller, 22”
25 1003727 1 • Tube, 22” Roller
26 3008027 1 • Shaft, 22” Roller
27 3005156 2 • Sleeve, Wear
28 3004882 2 • Seal, Grease
29 500534 2 • Bearing, Cup and Cone
30 367029 2 • Locknut, 3/4-16 Stover
31 4127335 2 Decal, Danger
32 4181863 1 Decal, Read Manual For Service
33 400553 2 Pop Rivet, 0.125 x 0.390
